In the modern medical context, endoscopes are an essential instrument for diagnosis and treatment. Endoscopes are inserted into the human body through minimally invasive means, providing medical professionals with clear internal images for accurate diagnosis and treatment. The performance of the protective plate at the front end of the endoscope directly affects its imaging quality and its lifespan during use. Sapphire glass, with its unique physical and chemical properties, has become an ideal material for endoscope protective plates. This article will explore the advantages of using sapphire glass as an endoscope protective plate.

Primarily, sapphire glass possesses both high hardness and wear resistance, which enables it to effectively resist the friction and scratches encountered when the endoscope moves inside the human body. In the procedure known as an endoscopy of the digestive tract, the endoscope must pass through areas such as the oesophagus, stomach and intestines. In such environments, the protective film can be subject to wear and tear from food residues, digestive juices and mucous membranes. Traditional glass or resin materials are susceptible to scratches in such environments, which can compromise the clarity of the image. Sapphire glass, on the other hand, is known for its ability to maintain a smooth surface over an extended period, thereby ensuring that image quality remains consistent.

In addition, sapphire glass is characterized by its excellent chemical stability. The internal environment of the human body is complex, with various corrosive liquids such as gastric acid and bile present. Ordinary glass is prone to corrosion in such environments, which can lead to surface fogging or the formation of microcracks. Sapphire glass is renowned for its exceptional resistance to acids and alkalis, maintaining stability across a broad pH range from 1 to 14.

In terms of optical performance, sapphire glass also performs exceptionally well. Its light transmission range extends from ultraviolet to infrared, with a light transmittance rate of over 85%, significantly exceeding the 70-80% range typically achieved by conventional optical glass. The excellent light transmittance of this endoscope ensures that it can obtain more realistic and clearer images. Especially in conjunction with advanced technologies such as narrowband imaging and laser confocal microendoscopy, sapphire glass reliably transmits light at specific wavelengths without causing optical dispersion and distortions.

Sapphire glass is notable for its thermal stability, which is a significant advantage. During the disinfection process of endoscopes, they must be able to withstand high-temperature and high-pressure steam sterilization. Ordinary glass materials are susceptible to stress cracking or deformation when subjected to repeated high-temperature treatment. Sapphire glass has a melting point of 2050°C and a coefficient of thermal expansion of 5.3×10-6/°C, making it well-suited to conventional disinfection conditions.

From the perspective of biocompatibility, sapphire glass fully complies with the safety standards for medical devices. It is free from harmful substances such as heavy metals and will not cause rejection reactions in the human body. The high biocompatibility of sapphire makes it an ideal material for use in endoscopes that require long-term indwelling in the body, such as working channel protective plates used in biliary stent implantation.

In terms of structural design, the processing performance of sapphire glass also creates opportunities for innovation. Sapphire glass can be processed into various complex shapes using laser cutting and polishing techniques, thus meeting the design requirements of different endoscopes. For instance, the protective window for the forceps lift of a duodenoscope requires a special curved surface design. Sapphire glass can be precisely processed into the required shape while retaining its edge strength. Additionally, sapphire glass can be reliably encapsulated with other materials to ensure the overall sealing and durability of the endoscope.

Sapphire glass is a protective plate for endoscopes which offers a number of advantages, including high hardness, corrosion resistance, good optical performance, strong thermal stability, and excellent biocompatibility. These characteristics enhance the imaging quality and durability of endoscopes, creating conditions for the application of new technologies.
